N1661VC420 CONVERTOR SCR 100*33MM thyristor

Features:
. All Diffused Structure
. Spoke Amplifying Gate Configuration
. Blocking capabilty up to 4200 volts
. Guaranteed Maximum Turn-Off Time
. High dV/dt Capability
. Pressure Assembled Device

Categories ,

N1661VC420 CONVERTOR SCR 100*33MM thyristor

ParameterSymbolMin.Max.Typ.UnitsConditions
Average value of on-state currentIT(AV)   1661ASinewave,180o conduction,TS=55oC
RMS value of on-state currentITRMS   3259ANominal value
Peak one cpstcle surge

(non repetitive) current



ITSM



25000



A

10.0 msec (50Hz), sinusoidal wave-

shape, 180o conduction, Tj = 125 oC

I square tI2t 3.1×106 A2s10.0msec
Latching currentIL     500 mAVD = 24 V; RL= 12 ohms
Holding currentIH      500 mAVD = 24 V; I = 2.5 A
Peak on-state voltageVTM     2.35VITM = 3220 A; Tj = 125 oC
Critical rate of rise of on-state

current (5, 6)

di/dt      200A/msSwitching from VDRM £ 1000 V,

non-repetitive

Critical rate of rise of on-state

current (6)

di/dt      100A/msSwitching from VDRM £ 1000 V
